NETWORK STANDARDS
802.11g wireless LAN
802.11b wireless LAN
802.3/802.3u 10BASE-T/100BASE-TX Ethernet
ANS/1EEE 802.3 NWay auto-negotiation

DEVICE INTERFACES
802.11g wireless LAN
2 10/100BASE-TX Ethernet LAN ports

OPERATING FREQUENCY
2.4 to 2.4835 GHz

RADIO & MODULATION SCHEMES
DQPSK, DBPSK, CCK, OFDM

ANTENNA
2dBi Gain detachable omni-directional antenna with RP-SMA connector

SECURITY
64/128-bit WEP encryption
WPA-PSK, WPA2-PSK
WPA-EAP, WPA2-EAP
TKIP, AES
MAC address filtering
SSID broadcast disable function

DEVICE MANAGEMENT
Web-based management through Internet Explorer v.6 or later, Netscape Navigator v.6 or later or other Java-enabled browser

POWER INPUT
5VDC 2A
External power adapter

DIAGNOSTIC LEDs
Power
Status
Link/Act
WEP/WPA
MAC Ctrl
BRIDGE/REPEATER
LAN1
LAN2

DIMENSIONS
144 (W) x 109 (D) X 30 (H) mm

WEIGHT
231grams

CERTIFICATION
FCC Class B
CE
C-Tick
Wi-Fi
